ALVTechnologies Philippines Incorporated, together with our manufacturer from Oxford Instruments Asylum Research, would like to invite you to join our webinar on the topic of Advancing full wafer and compound semiconductor research with Raman & Photoluminescence imaging on July 16, 2025, 2:00 PM (Philippine Time).
Semiconductors are the materials from which the engines of the information age are built, and their advancement is among the most vital endeavors in technology. The first step in their production generally involves crystal growth and sectioning into thin wafers. The wafers are then altered using methods such as doping to give them specific electronic properties. Access to the subtlest details of these chemical and structural modifications on the sub-micrometer scale is crucial in new device development and final product quality control.
In this webinar, you will learn:
- 3D Raman Imaging Principles: Understand the fundamentals of this powerful technique.
- High-Resolution Chemical Imaging: Learn how to achieve the highest spatial and spectral resolution for detailed analysis.
- Real-World Applications: See demonstrations on stress, doping, and topographic variative in large-area wafers and layered semiconducting materials.

To register, visit the following link: Webinar Registration
We hope to see you online!
